ANSI/HI 7.8-Controlled-Volume Metering Pump Piping Guideline

Overview:

This standard covers interactions of inlet (suction) and outlet (discharge) piping on metering system performance.  This guideline applies to controlled-volume metering pumps, specifically those with pulsating flows. Types of positive displacement pumps include, but are not limited to, hydraulic-coupled disc diaphragm, hydraulic-coupled tubular diaphragm, mechanical-coupled disc diaphragm, packed piston, and plunger.

Controlled-volume metering pumps are commonly in industry segments including chemical, petroleum, slurry, water and wastewater, residential, electric power and more. System designers should use this guideline to ensure optimal performance and reliability of the controlled-volume meter pump.

What’s New:

This standard supersedes the ANSI/HI 7.8-2016 edition. Updates in the new edition include:

  • Revised equations on NPSH/NPSHR conversions
  • Updated definitions section

Print copies typically ship within 3 business days.

Have questions? Please contact us through our Customer Support Center.

table of contents
important information on pdfs
Return Policy

Leave a Comment

Related , ,

ANSI/HI 7.8-Controlled-Volume Metering Pump Piping Guideline

$70.00

Discount pricing available for members. Become a member or Login.
ISBN: 978-1-954671-04-1

Current version: Yes

Version history: 2016

Part of Package(s):
Complete Set - Hardcopy 5-Binder Set - ANSI/HI Pump Standards, Complete Set Bundle - Hardcopy and Web-based Subscription - ANSI/HI Pump Standards, Complete Set Bundle - Hardcopy and (Single User) Web-based Subscription Set - ANSI/HI Pump Standards, TESTING M100 Copy-Complete Set - Hardcopy 5-Binder Set - ANSI/HI Pump Standards

Categories: , ,
